TP304 / 1.4301 Stainless Steel Seamless Pipe Big Size 20 Inch for Oil / Gas

TP304 / 1.4301 Stainless Steel Seamless Pipe Big Size 20 Inch for Oil / Gas
TP304 / 1.4301 Stainless Steel Seamless Pipe Big Size 20 Inch for Oil / Gas TP304 / 1.4301 Stainless Steel Seamless Pipe Big Size 20 Inch for Oil / Gas

TP304 / 1.4301 Stainless Steel Seamless Pipe Big Size 20 Inch for Oil / Gas

পণ্যের বিবরণ:
Place of Origin: CHINA
পরিচিতিমুলক নাম: MTSCO
সাক্ষ্যদান: ISO 9001 & PED & AD2000
Model Number: MTSCOSSSP25
প্রদান:
Minimum Order Quantity: negotiable
মূল্য: 2900-10000USD/TON
Packaging Details: Plywood Case
Delivery Time: 30 Days
Payment Terms: T / T ; L / C
Supply Ability: 300 Tons / Month
এখন যোগাযোগ

বিস্তারিত তথ্য
উপাদান: TP304 / 1.4301 ভূতল: pickling
NDT: এডি বর্তমান বা জলবাহী টেস্ট শেষ কাটা: সমভূমি
হাতের অক্ষর: উভয় প্রান্তে প্লাস্টিকের ক্যাপ সঙ্গে নিরীক্ষা: 100%
লক্ষণীয় করা:

seamless stainless pipe

,

seamless stainless tube

পণ্যের বর্ণনা

TP304 / 1.4301 Stainless Steel Big Size 20 Inch Seamless Pipe In Oil And Gas





Grade



 TP 304; TP304H; TP304L; TP316; TP316L; TP 321;TP321H; TP317L; TP310S; TP347H

Standard



 ASTM A213, ASTM A 269, ASTM A 270,EN10216-5; ASTM B 622;ASTM B516;ASTM A789, etc
Size OD:6.35-44.5mm (1/4”-1 3/4”)
  WT:0.71-3.81mm (0.028”-0.15”)
  Length:Max.12M
Advantage Superior surface finish ,better mechanical property; more precise dimension; perfect inspection method and inspection equipment
Application

Boiler tube applies to petroleum,chemical industry,electric power,boiler,high temperature

resistant,low temperature resistant,corrosion resistant.The size can be made according

to the customers requirements.High pressure boiler pipe applies to container,petrochemical

and so on.Note:Generally,high pressure boiler pipe’s working pressure above 9.88Mpa and

working temperature between 450 to 650.



TP304 / 1.4301 Chemical compostion :

1 . (C) Carbon , max : 0.08

2 . (Mn) Manganese , max : 2

3 . (P) Phosphorus , max : 0.045

4 . (S) Sulfur , max : 0.030

5 . (Si) Silicon , max : 1

6 . (Ni) Nickel : 8.0 - 11.0

7 . (Cr) Chromium : 18.0 - 20.0

8 . (Mo) Molybdenum : --

9 . (Fe) Iron : --

10 . (Cu) Copper : --

11 . (N) Nitrogen : --





Material Grade :



American Standard Austenitic Steel:
TP304,TP304L,TP304H, TP304N, TP310S,TP316,TP316L,TP316Ti,TP316H, TP317,TP317L, TP321, TP321H,TP347, TP347H,904L…
Duplex Steel :
S32101,S32205,S31803,S32304,S32750, S32760
Others:TP405,TP409, TP410, TP430, TP439,...
Europen Standard 1.4301,1.4307,1.4948,1.4541,1.4878,1.4550,1.4401,1.4404,1.4571,1.4438, 1.4841,1.4845,1.4539,1.4162, 1.4462, 1.4362, 1.4410, 1.4501



TP304 / 1.4301 Stainless Steel Seamless Pipe Big Size 20 Inch for Oil / Gas 0



Industry & Advantage

Application

a) For fluid & gas transport

b) Structure & machining etc

Advantages

a) Advanced technology of cold draw machine

b) Advanced annealing machine

c) Better mechanical property

d) More precise dimension

e) Perfect inspection method and inspection equipment etc



1 . Our company has been dedicated to producing seamless stainless steel pipe since 2003 , owning complete producing technology and abundant managing experience .

2 . The raw material such as mother tube , round bar we use is from Chinese biggest and well-known steel mill : Walsin , Yongxing etc .

3 . We have advanced NDT equipments for the tests such as Eddy Current test, Ultrasonic test , Hydraulic test and so on .

4 . We have ISO 9001 and PED certificate , and the Third Party Inspection Certificates such as TUV , BV , Lloyd’s , SGS , etc , also can be provided according to customers’ requirements .
